Car Tuning 101: What is it & How it Works
|
|
Time to read 9 min
|
|
Time to read 9 min
Car tuning refers to the process of modifying a vehicle's engine control unit (ECU/DME) parameters to improve performance, throttle response, and drivability. In simple terms, we are overwriting the manufacturer's calibration with our own to optimize for your modifications, fuel quality, and environment.
Tuning changes how your car’s engine behaves by adjusting variables like:
● Air-to-fuel ratio (AFR)
● Ignition timing
● Forced Induction boost control
● Throttle mapping
● Rev limiters and speed governors
● Variable valve timing
● Many more
The result? Increased horsepower and torque, smoother shifting, improved throttle sensitivity, and overall a more enjoyable experience with your car.
Modern vehicles rely on an ECU or DME—a small computer that controls how the engine runs. By accessing and modifying the ECU’s software, we can change how the engine behaves under different conditions. Depending on the platform we use a variety of software suites such as EcuTek, MHD, Bootmod3, or HP Tuners.
There are two popular options for tuning::
There are a few different ways to tune a car depending on your goals and limitations. We are located in Houston, TX but we have dealers and customers all over the globe.
Dyno tuning is performed on a dynamometer—a machine that measures power output while simulating real-world load conditions. Think of it like a treadmill for your car. It gives tuners a safe, controlled environment to adjust the ECU in real time and adds another layer of data - a power and torque graph. Dyno tunes are the most effective for high horsepower cars where we need to limit horsepower or torque for engine safety, or when learning a new platform. It also allows you to see the exact power output of a car, although dynos can read differently from dyno to dyno. It's best to run a baseline in stock form to see the power gains rather than relying on the exact power figure spit out by the dynamometer.
Remote tuning is performed on the street by the customer. Once the customer flashes the tune file to the ECU, they will need to complete data logs so the tuner can dial in the tune. These data logs often require wide open throttle (WOT) pulls through various gears, but can also include capturing idling and normal driving depending on what the tuner needs to dial in. Remote tunes are best for dialing in with real world conditions and are more cost effective than a dyno tune.
Dyno tuning would be advantageous if you do not want to do the data logging on your own or do not have access to a private road for the data logging process.
Remote tuning is by far our most popular option as you can data log at your own convenience. We will take about 1-2 business days to review your data log and get back to you. For our tuning process, we do not require you to respond right away but you do have 90 days to finish the tuning process with us from the first date the initial tuning file was sent. OTS files from Racebox do not require data logging. However, if you have a specific concern regarding your car, you are welcome to send in a data log for review by our tuners. Keep in mind, certain tunes such as flex fuel may take several revisions as we start off with pump gasoline then move onto your car’s specific target ethanol mixture.
This depends on your tuner’s experience with your platform. For many vehicle setups, we have our tuning strategies honed to a tee and it’s better to dial in fueling, boost, and timing in real world conditions (remote tune) as loads vary greatly between a dyno and an actual road. If we are unfamiliar with a particular turbo, fuel component, etc, we may ask to do a dyno/remote-dyno as we can keep a close eye on critical parameters during the tuning process. Plus, we can make rapid changes and they will be within a reasonable constant environment (dyno load, temps, etc). The other time dyno tuning is beneficial is when power or torque needs to be limited to protect weaker components such as stock engine or a stock transmission.
When done correctly by an experienced tuner, tuning can be very safe. We base all custom calibrations on:
● Your vehicle’s exact modifications
● Your environment, such as elevation and climate
● Manufacturer safety limits determined by our extensive knowledge of testing the drivetrain’s limits
● Extensive logging and data review
Tuning can void your warranty, especially if the dealership spends the time and effort to determine if the ECU has been altered. However, many tuning platforms offer ways to revert to stock before dealer visits. It’s always best to weigh the risk vs. reward and check with your manufacturer or dealer before tuning. In addition, we would advise you to speak with your local dealership to feel them out for what modifications will void warranties. Dealerships do have some discretion and will vary from location to location.
“I got the same modifications as my buddy and he’s faster!” Well, let’s break it down.
Engine Variance: Not every engine is built the same and if your engine has wear and tear, that can also impact engine output even with the same modifications down to the brand. We’ve put hundreds of cars on our dyno with identical modifications and power can vary as much as 40 + WHP/WTQ. When customers come to us and ask us for a power figure their car will make with a specific mod set, we always give a broad range with this information in mind.
Weight: This goes without saying, but less weight will equal a faster car. Removing static weight such as removing interior components (seats, panels, etc.), upgrading components to lightweight items (2 piece rotors, carbon fiber hood/doors, etc.) can shed hundreds of pounds given the extent they go to.
DA (Density Altitude): Depending on where you live, this can play a big difference in your times. DA is a reading composed of pressure, temperature, and humidity. We are in Houston, TX which has a sub tropical climate and about 50 ft above sea level. In recent years, we’ve had extreme summers (100 + F/90% + humidity) and some cooler weather than usual (25 + F) which can impact performance. I have two solid examples where we take one particular car with the same tune, same modifications, and run them in two drastically different temperatures.
This is a BMW M4 (G82) with SPOOL hybrid turbos, upgraded fuel system, built transmission and tuned on MHD +. This car is making upper 800’sWHP and has 0 weight reduction. In the summer months, it’s running a low 5 second 60-130 MPH in 3K DA. In cooler months with absolutely no change to the car, we see that 60-130 MPH metric dip down to 4.69s.
Driver mod: Yes, even automatic cars require driver mod. Sometimes, your friend just knows their car better than you, can handle it better, or has better traction.
There are three parts to tuning costs: hardware, licensing, and the tune itself.
● The hardware needed to tune a car is an OBD II module and they typically run about $80 - $250 but can vary depending on the software used. Certain software such as EcuTek require their own specific module to interface with their app.
● Licensing costs are generally around $600 but vary depending on software used and vehicle tuned.
● Tuning costs vary based on modifications, vehicle being tuned, and software.
○ OTS tunes are the cheapest offerings and are around $300–$600.
○ Custom remote tunes for simple bolt on modifications are around $500-$700. Modifications like turbos, or flex fuel can bring the cost around $1500-$2000.
○ Dyno tuning generally charges a flat rate or by the hour depending on the dyno shop, the additional cost for dyno tuning is around $300-$600.
In total, for a car that has never been tuned before you can expect to spend anywhere from $300 (if you already have the hardware and licensing from a previous tuner) to $2000 including hardware, licensing, and tuning costs.
You can visit our Houston location or one of our approved vendors below:
● 2121 Brittmoore, Suite 3200, Houston, TX, 77043
● 18 Neil Ct, Oceanside, NY 11572
● 4270 NW 19th Ave F, Deerfield Beach, FL 33064
● 13470 SW 128th St, Miami, FL 33186
● 8224 Veterans Hwy Unit 1, Millersville, MD 21108
● 8041 Queenair Dr #8, Gaithersburg, MD 20879
At Racebox, we’ve tuned thousands of cars globally across multiple platforms. Our success is driven by our precise, reliable, and powerful tunes paired with our industry leading response time of 1-2 business days. As our customer base and demand continues to grow, we have grown our team to ensure we can always offer the best support and maintain our quick turnaround times.
Here are some of the platforms we support:
● BMW (B58, S58, S55, N63, S63)
● Infiniti/Nissan (VR30DDTT, VR38DDTT, VQ37VHR, VQ35DE, VQ35VHR, VK56D)
○ We have tuned the most VR30s in the world
● Toyota Supra A90 & GR 86
● Audi & VW (4.0T, DAZA, MQB)
How does remote tuning work?
Remote tuning allows us to calibrate your vehicle’s ECU from anywhere in the world, without requiring an in-person visit. Here’s how it works:
Purchasing: Select your platform (e.g., Infiniti, BMW, Nissan, etc) from the Racemode drop-down menu on our website and choose the appropriate options. Once purchased we will ship out your hardware and email you instructions to begin the tuning process.
Preparation: Ensure all maintenance items (e.g., oil changes, spark plugs, filters, tires,etc..) are up to date. Install any modifications you’ve communicated to us (e.g., larger intakes, high-pressure fuel pumps, turbocharger) before flashing your car with the base calibration file.
Process: You’ll receive a base calibration file and detailed flashing/data logging instructions. A fully charged battery or a battery tender is highly recommended during the flashing process. Custom tuning customers will log data for review, while OTS tuning doesn’t require data logging.
Data logging: Depending on the platform, we will ask you to perform wide open throttle pulls in a specific gear from a certain RPM to redline while data logging. Data logging will need a specific set of parameters selected and will be detailed in our tuning instructions. You will need a safe stretch of road to perform the data logs. If this is not an option for you, you are welcome to find a local dyno and coordinate a remote dyno tuning session with us.
Map Selection: When getting a custom tune with us, the base file will have only 2 maps (Daily & Racemode) which are meant to be low/high power maps. After completing the data logging and revision process, we’ll finalize the tune and offer additional map options.
